Must 2KW Series High-Frequency Off Grid Solar Inverter PV18-2024 VPM This is a multi-function inverter/charger, combining functions of inverter, MPPT 60A/80A solar charger ,and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operations such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications. Features: Rated power: 1-5KW Pure sine wave output Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc). • Bult in MPPT 60A\80A solar charge controller Combining solar system, AC utility, and battery power source to supply continuous power Overload, short circuit, and Deep discharge protection Cold start function Support USB, RS485 monitoring function WIFI remote monitoring (optional) Compatible to the generator Support parallel operation up to 3 units (available for 3KW-5KW 48V) INVERTER OUTPUT Rated Power 2000VA \ 2000W Surge Power 4000VA Waveform Pure sine wave AC Voltage Regulation (Batt. Mode) (220VAC~240VAC)±5% Inverter Efficiency(Peak) 93% Transfer Time 10ms(UPS / VDE4105) / 20ms(APL) AC INPUT Voltage 230VAC Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE) Frequency Range 50Hz / 60Hz (Auto sensing) BATTERY Normal voltage 24VDC Floating Charge Voltage 27.4VDC Overcharge Protection 30VDC SOLAR CHARGER & AC CHARGER Maximum PV Array Open Circuit Voltage 145VDC PV Array MPPT Voltage Range 30~120VDC Standby Power Consumption 2W Maximum PV Array Power 1500W Maximum Solar Charge Current 60A Maximum Efficiency 98% Maximum AC Charge Current 20A/30A Maximum Charge Current 80A MECHANICAL SPECIFICATIONS Machine Dimensions (W*H*D)(mm) 272*355*100 Package Dimensions (W*H*D)(mm) 485*393*251 Net Weight(kg) 7.4 Gross Weight(kg) 9.5 OTHER Humidity 5% to 95% Relative Humidity (Non-condensing) Operating Temperature 0°C~50°C Storage Temperature -15°C -60°C
