Synology WRX560 Wi-Fi 6 Intelligent Mesh Router | WRX560
Hardware
Specs
CPU
Quad core 1.4 GHz
Hardware Acceleration Engine
Layer 4 / Layer 7
Memory
512 MB DDR4
Antenna Type
4x4 MIMO high-performance internal antenna (5 GHz)
2x2 MIMO high-performance internal antenna (2.4 GHz)
LAN Port
2.5GbE (RJ-45) x 1
Gigabit (RJ-45) x 3
WAN Port
Gigabit (RJ-45) x 1
2.5 GbE (RJ-45) x 1 (Dual WAN)
External Ports
USB 3.2 Gen 1 x 1 (5V, 0.9A power output)
IEEE 802.11ax
IEEE 802.11a/b/g/n/ac/ax
2.4GHz: 600Mbps
5GHz: 2400Mbps
Simultaneous dual-band Wi-Fi
Wi-Fi Encryption
WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, Wi-Fi Enhanced Open (OWE)
Button and Switch
WPS, Power, Reset, Wi-Fi On/Off
Size (Height x Width x Depth)
233 mm x 194 mm x 66 mm
Weight
1.35 kg
Temperature
Operating Temperature
5°C to 40°C (40°F to 104°F)
Storage Temperature
-20°C to 60°C (-5°F to 140°F)
Relative Humidity
5% to 95% RH
Certification
FCC
UKCA
CE
BSMI
VCCI
RCM
KC
iDA
TELEC
JATE
IC
Wi-Fi Certification
CE
UKCA
FCC
NCC
RCM
iDA
TELEC
KC
IC
AC Input Power Voltage
100 V to 240 V AC
Power Frequency
50/60 Hz, Single Phase
Power Consumption
10.80 W (Access)
7.94 W (Idle)
Environment
RoHS Compliant
